Atlas developed the Mercury Series anamorphic Lenses to reimagine the possibilities of what an anamorphic lens could be and truly put the world of cinematography in your hands.

 Featuring a 1.5x squeeze ratio, Atlas Mercury Lenses deliver stunning anamorphic characteristics such as oval bokeh and streak flares.
With focal lengths ranging from 24mm to 138mm, the Mercury Series offer universal focal range versatility no matter your sensor size or aspect ratio.

-Vintage Sun-Tinged Golden Flares
-Attractive Expressionist Geometric Distortion
-Classic Anamorphic Field Curvature and frame fall off
-Near Apochromatic Color Correction
-Fast T2.2 Aperture through most of the range

The first truly Universal Anamorphic Lens - by design - ready for wherever your creativity takes you.

Broadly compatible with all film and digital systems and delivery formats:

-16mm Film
-35mm Film (3 Perf and 4 Perf)
-35mm Digital and (S35 and APS-C formats)
-VistaVision Film (36mmx24mm open gate)
-Full Frame Digital such as the Arri Alexa Mini LF, Sony Venice 2, BlackMagic Design Ursa Cine 12K LF and more
-Beyond Full Frame Digital Systems like the Arri Alexa 265, BlackMagic Design Ursa Cine 17K, and new FujiFilm Eterna.
Universal Delivery Aspect Ratios:
-2.76:1
-266:1 Open Aperture Cinemascope
-2.40:1/2.39:1/2.35:1 Widescreen
-2:1 Storaro Univisium / Netflix
-1.89:1 / 1.85:1 WideScreen / DCI
-16:9/17:9 TV Formats
-1:1, 4:3, 4:5, 9:16 New Territory and Social Media

Technical_Specifications

View full details
  • Atlas Lens Co. Mercury Series Logo

Atlas Mercury - The Universal Anamorphic Lens

Filmed on Atlas Mercury Series

9 to 5 | Filmed on Atlas Mercury 24/27mm

Bridget Taylor & Sonali Chugani
Shari works a dumb job. It’s all computers, fax machines, and staplers. But her life doesn’t revolve around her accomplishments as an accountant. She works so she can pursue her real passion: Being a rave tattoo artist.

Ascend | Filmed on Atlas Mercury 24/27mm

Steph Verschuren
"Mercury Ascend" is a shot-on-35mm fusion of high-energy athletic cinematography and playful self-awareness, crafted to showcase the 27mm and 24mm Atlas Mercury lenses through professional bouldering.

Porsche Legacy | Filmed on Atlas Mercury Series

Aaron Romo
We zig and zag through the canyons in this Porsche commercial directed and DP'd by Aaron Romo!

Rocketman | Filmed on Atlas Mercury Series Group II

Julien Jarry
Whizzing across the sandy expanse, Robert Maddox reveals his backstory in this mini-commercial brought to life by the incredible Julien Jarry.

Fly | Filmed on Atlas Mercury Series Group II

Jon Pears
In the heart of the majestic Alps, where snow-clad peaks touch the heavens, Jon Pears captures the mesmerizing journey of Stefan Langer as he embarks on an ethereal adventure.

My Own Eyes | Filmed on Atlas Mercury Series

Vanessa Vandy
Faced with the challenge of inspiring a classroom full of disillusioned youth, professor Josephine Rao delves into the recesses of her own past to draw out universal truths that both excite and inspire.
1
2
3
4
5
6

The Lineup

Focal Length 24mm27mm32mm 36mm42mm54mm72mm95mm138mm
T-Stop Range T2.2 - T16T2.2 - T16T2.2 - T16 T2.2 - T16T2.2 - T16T2.2 - T16T2.2 - T16T2.2 - T16T2.6 - T16
Min Focus 1.5 ft / 0.46 m1.5 ft / 0.46 m1.5 ft / 0.46 m 1.5 ft / 0.46 m2.0 ft / 0.56 m2.5 ft / 0.76 m3.0 ft / 0.91 m3.0 ft / 0.91 m4.0 ft / 1.2 m
Weight 3.85 lbs / 1.75 kg3.25 lbs / 1.47 kg3.25 lbs / 2.41 kg 2.7 lbs / 1.2 kg2.3 lbs / 1.1 kg2.95 lbs / 1.3 kg3.6 lbs / 1.6 kg4.4 lbs / 2.0 kg4.7 lbs / 2.1 kg
Length 5 in / 12.8 cm5.5 in / 13.97 cm5.38 in / 13.67 cm 4.9 in / 12.6 cm4.4 in / 11.2 cm5.0 in / 12.8 cm6.3 in / 16.2 cm6.9 in / 17.6 cm8.1 in / 20.5 cm
Front Diameter 114 mm95 mm95 mm 95 mm95 mm95 mm95 mm95 mm95 mm
Image Circle Full Frame (36.7 mm × 25.54 mm)
Horizontal FOV (Full Frame) 132°117°99° 88°78°60°44°32°23°

Note: Field of view measurement with lens set to Infinity and Full Frame gate (36mm)

Mercury Accessories

"The world of cinematography is now available in your hands with the Mercury Series, a universal anamorphic lens, designed to be your lifetime creative tool no matter where your passion or career take you."

The Mercury Series represent a bridge between the best of the history of anamorphic cinematography, and the best possible future for creatives around the world. No matter where they are in their journey, these lenses will carry their dreams. Atlas Mercury Series are a love letter to everything we cherish about cinema history, and desire to pioneer for a new generation of filmmakers now and forever.

Modern Conveniences

  • Full-frame sensor coverage with 1.5x anamorphic coefficient

  • Aperture of T2.2 for Mercury Series 36mm

  • Lightweight and compact: Half the size and weight of most pro anamorphic lenses

  • Standardized gears and diameters with 95mm front diameter

  • Unified focus and iris position (reduces need for adjustment when switching to different focal lengths)

Optical Personality

  • Warm vintage tones with golden streak flares

  • Enhanced bokeh

  • Exceptional optical performance with vintage geometric personality

  • Near-zero chromatic aberration

  • Pleasing, classic anamorphic barrel distortion

More personality, zero compromises

The Mercury Series showcases exceptional optical performance, color performance, and clarity with vintage geometric personality. The Mercury lenses feature a golden lens flare when direct light sources hit the glass. They also have excellent close-focus with near-zero chromatic aberration, allowing Mercury Series lenses to be used in all kinds of demanding scenarios. The Mercury Series lenses are crisp, resolute, and optimized to bring out the beauty in a variety of skin tones.

Mercury goes wherever your stories take you

Our talented team of designers and engineers examined the needs of cinematographers around the world to create a new line of anamorphic lenses meant to be used on any set, in any rig configuration - whether on land, sea, or air: from the largest production, to solo operator run-and-gun, aerials, underwater, or anywhere in between.

With full-frame coverage, a 1.5x squeeze ratio with enhanced bokeh, a dynamic geometric optical personality and warm vintage tones, and exceptional optical performance -- all at half the size and weight of most pro-anamorphic lenses.

The Specs

  • Full-frame sensor coverage with 1.5x anamorphic coefficient
  • Aperture range from T2.2 - T16 for Mercury 42mm
  • Lightweight and compact at half the size and weight of most pro-anamorphic lenses - 42mm weighs 2.3lbs (1.1kg) and measures 4.4in (11.2cm) in length
  • Exceptional optical performance with vintage geometric personality: Golden flares, pleasing barrel distortion, near-zero chromatic aberration
  • Standardized gears and diameters with 95mm front diameter
  • Arri PL mount
