Atlas Lens Co
Orion Series Silver Edition Anamorphic Lenses
Orion Series Silver Edition Anamorphic Lenses
SKU:N018SEI
Couldn't load pickup availability
The Silver Edition lenses maintain the modern, mechanically reliable performance that sets the Orion Series apart from vintage anamorphic lenses, all while celebrating aspects of the silver screen cinema era.
Precision-adjusted air space tunings paired with bold Silver Edition coatings result in expressive, reactive, yet chromatically refined anamorphic flares unlike any lens before.
Share

Introducing Orion Series Silver Edition
Lens Specifications
| Focal Length | 18mm | 21mm | 25mm | 28mm | 32mm | 40mm | 50mm | 65mm | 80mm | 100mm | 135mm | 200mm |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| T-Stop Range | T2 - T16 | T2.2 - T16 | T3.2 - T16 | |||||||||
| Min Focus | 1.5 ft / .45 m | 1.5 ft / .45 m | 1.5 ft / .45 m | 1.75 ft / .53 m | 2.0 ft / .56 m | 2.5 ft / .76 m | 2.75 ft / .84 m | 3.0 ft / .91 m | 3.0 ft / .91 m | 3.5 ft / 1.1 m | 3.5 ft / 1.1 m | 3.5 ft / 1.1 m |
| Weight | 6.95 lbs / 3.15 kg | 6.9 lbs / 3.1 kg | 6.2 lbs / 2.8 kg | 6.5 lbs / 2.9 kg | 4.7 lbs / 2.1 kg | 5.2 lbs / 2.4 kg | 5.0 lbs / 2.3 kg | 5.0 lbs / 2.3 kg | 6.0 lbs / 2.7 kg | 6.7 lbs / 3 kg | 8.8 lbs / 3.99 kg | 9 lbs / 4 kg |
| Length | 7.4 in / 18.7 cm | 7.4 in / 18.7 cm | 7.4 in / 18.7 cm | 7.4 in / 18.7 cm | 7.4 in / 18.9 cm | 7 in / 17.8 cm | 7.2 in / 18.4 cm | 8.4 in / 21.2 cm | 9.8 in / 25 cm | 12 in / 30.5 cm | 12.95 in / 32.9 cm | 12.95 in / 32.9 cm |
| Front Diameter | 136mm | 114mm | ||||||||||
| Image Circle | 31mm (4-perf Super 35) | |||||||||||
| Horizontal FOV | 140° | 124° | 109° | 98° | 88° | 66° | 55° | 43° | 35° | 28° | 20.9° | 14.4° |
- 14 blade iris, all elements are glass (no plastics). Lens body is coated in scratch-resistant anodized aluminum.
- The measurement from flange to the back of the glass is 18.45mm on the deepest lens (32mm T2).
- Accepts 105mm screw-in filter to facilitate drone and gimbal use (40mm–100mm).
- For additional stability, lens feet and support brackets are available for purchase.
Orion Silver Edition Accessories
-
Atlas 1.6x LF Extender
Regular price From $1,849.00 USDRegular priceUnit price / perSale price From $1,849.00 USD -
Atlas 1.4x LF Expander
Regular price $2,499.00 USDRegular priceUnit price / perSale price $2,499.00 USD -
4 Lens Modular Case (Case only)
Regular price $593.00 USDRegular priceUnit price / perSale price $593.00 USD -
Mercury 95mm Front Lens Cap
Regular price $20.00 USDRegular priceUnit price / perSale price $20.00 USD -
Modular Lens Case Foam
Regular price $89.00 USDRegular priceUnit price / perSale price $89.00 USD -
Orion Shim Pack
Regular price From $44.00 USDRegular priceUnit price / perSale price From $44.00 USD -
Orion B-Set Three-Lens IP67 Case
Regular price $499.00 USDRegular priceUnit price / perSale price $499.00 USD -
Orion A-Set Three-Lens IP67 Case
Regular price $499.00 USDRegular priceUnit price / perSale price $499.00 USD -
Lens Support Foot
Regular price $39.99 USDRegular priceUnit price / perSale price $39.99 USD -
Orion 114mm Front Lens Cap
Regular price $20.00 USDRegular priceUnit price / perSale price $20.00 USD -
Orion Focus Scales
Regular price From $299.00 USDRegular priceUnit price / perSale price From $299.00 USD -
3 Lens Modular ATA Case (Case only)
Regular price $582.00 USDRegular priceUnit price / perSale price $582.00 USD -
Orion Single Lens IP67 Case
Regular price $149.00 USDRegular priceUnit price / perSale price $149.00 USD -
Orion Telephoto Double-Lens ATA Case
Regular price $749.00 USDRegular priceUnit price / perSale price $749.00 USD -
Orion Telephoto Single-Lens ATA Case
Regular price $649.00 USDRegular priceUnit price / perSale price $649.00 USD
"Our goal was to break new ground — building the tools we wanted to use but couldn’t attain."
Nine years ago, Atlas Lens Co. started on the path to make cinematography more interesting, more personal, and more rewarding. Our goal was to break new ground for cinematography through anamorphic lenses -- building the tools we wanted to use, but couldn’t attain.
As we developed greater capabilities, we built up a special reserve of selected optics, destined for unique coatings and precision augmented air spacings. Building a cache of special optics was a slow and dedicated process. This allowed us to dig deeper into how we might create a new, expressive and dynamic style of lenses that pay tribute to the rich history of cinema.
Express Your Vision For the Silver Screen
The Silver Edition lenses maintain the modern, mechanically reliable performance that sets the Orion Series apart from vintage anamorphic lenses, all while celebrating aspects of the silver screen cinema era.
Precision-adjusted air space tunings paired with bold Silver Edition coatings result in expressive, reactive, yet chromatically refined anamorphic flares unlike any lens before.
Modern Conveniences
-
Crisp flat-field performance when stopped down to a T2.8 or more
-
T2 aperture with pleasant spherical aberration glow when wide open
-
Modern, mechanically dependable design (standardized across all 6 focal lengths)
-
Unified focus and iris position (reduces need for adjustment when switching to different focal lengths)
-
136mm outer diameter for native use with a variety of matteboxes and filters
Dynamic Orion Characteristics
-
Extremely low distortion for an incredibly wide lens
-
Horizontal field-of-view with 2x anamorphic squeeze
-
18” (1.5’) minimum/close focus
-
Beautiful shallow depth-of-field
-
Compliments the Orion Series family of lenses
Filmed on Atlas Orion Silver Series
On the Orion - Atlas Orion Silver Edition Lens Test
THE GANG'S ALL HERE : Worble x Atlas
Technical Comparison with LF Extender
Orion SE and standard Orion Series
Technical Comparison without LF Extender
Orion SE and standard Orion Series
F-Stop Comparison
Orion SE and standard Orion Series
Orion Silver Edition Visual Demo
Orion SE with Arri Alexa Mini LF and RED Komodo
Manta Rays At Night | Filmed on Atlas Orion Silver Edition
Atlas Orion Silver Edition | Blackmagic Pocket 6K Pro short film "1712"
